Product Detail

XT Series

XT Series


Features and Benefits

• 12 years in floating condition

• Up to 5 years design life at renewable energy applications according to IEC61427

• Wide operating temperature range from -25°C to 65°C

• Nano gel electrolytes eliminate acid stratification and prolong cycle life

• Round trip efficiency as high as 85%

• Thick positive flat plate design with high Tin low Calcium alloy and high-density paste

• Low self-discharge rate and long shelf life (9 months at 20°C)


Collect
Product Detail

Range Summary

By combining a newly developed NANO gel electrolyte, a container with enhanced characteristics, and plates - horizontally positioned, pancake-style stacked, and compressed under 60 kPA - we created an innovative XT Series of batteries. The XT Series features 15 years of design life, front access terminals for fast installation and easy maintenance, and outstanding thermal resistance (works in up to 65°C).



Applications





                        UPS

                    Telecoms

            Power Transmission

                  Industrial EV


Documents

XT6-200G 2021.pdf

XT12-100G 2021.pdf


Specifications

         Model

Chemistry

Voltage (V)

Capacity (Ah)

Dimensions (mm)

Weight (Kg)

Terminal

XT6-200G

Lead-Acid

6

200

363 * 125 * 250

31.5

M8 Fem

XT12-100G

Lead-Acid

12

100

370 * 125 * 291

33

M8 Fem
