StatoDyne 12/100
Sodium Ion (Na) Technology
Applied in UPS or Standby/Backup
Applied in UPS or Standby/Backup
Product Lineup
Application Scenarios
-
UPS
-
Electrical Power
-
Telecom
Technical Specifications
| ltem | SIBPOM-12100 |
| Rated Capacity | 100Ah |
| Nominal Voltage | 11.4V |
| Discharging Cut-off Voltage | 6V |
| Charging Cut-off Voltage | 13.2V |
| Standard Charging | Continuous Current:100A Cut-off Voltage:13.2V |
| Standard Discharging | Continuous Current:100A Cut-off Voltage:6V |
| Max Continuous Charging Current | 100A |
| Max Continuous Discharging Current | 100A |
| Operating Temp.Range | Charging:-10~50℃ Discharging:-45~65℃ |
| Storage Temp.Range | 25±3℃ |
| Dimensions | 332*172*221(mm) |
| Weight | 14kg |
| Shipped Product Charging | 0% Power |
| Packaging Material | Cardboard |
