Product Detail

GB Series

GB Series



Features and Benefits

• 5 years of design life in floating condition

• Wide operating temperature range from -15°C to 55°C

• Can be used in a vertical or horizontal position

• Balanced design for both floating and cyclic operation

• Low self-discharge rate and long shelf life

• Excellent deep discharge recovery capability


Collect
Product Detail

Range Summary

The GB series offers a 5-year full maintenance-free design life. With a compact design and good reliability, this series is highly suited for security and alarm, systems, UPS systems, emergency light systems, and other small backup applications.


Applications





                       Power Transmission

                                   UPS


Documents

GB12-7 2021.pdf

GB12-1.3 2021.pdf

GB12-9 2021.pdf

GB12-12 2021.pdf

GB12-33 2021.pdf


Specifications:

         Model

Chemistry

Voltage (V)

Capacity (Ah)

Dimensions (mm)

Weight (Kg)

Terminal

GB12-1.3

Lead-Acid

12

1.3

98 * 43.5 * 58

0.56

F1

GB12-7

Lead-Acid

12

7

151 * 65 * 100

2.1

F1/F2

GB12-9

Lead-Acid

12

9

151 * 65 * 100

2.6

F2

GB12-12

Lead-Acid

12

12

151 * 98 * 100

3.6

F2

GB12-33

Lead-Acid

12

33

195 * 130 * 164

9.4

M6 Fem
