Product Detail

FAB Series

FAB Series



Features and Benefits

• 12 years of design life in floating condition

• Wide operating temperature range from -15°C to 60°C Advanced paste formula with

increased recharge efficiency

• Front access terminal with standard width for 19” and 23” ETSI racks

• 30% decreased float current leads to excellent high-temperature resistance

• Thick flat plate with high Tin low Calcium alloy

• Low self-discharge rate

• Excellent deep discharge recovery capability


Collect
Product Detail

Range Summary

The FA (Front Access) Series is specially designed for telecommunication use with 12 years of design life in float service. By combining the newly developed paste formula with up-to-date AGM structures, this range features 12 years of design life and a Front Access connection for fast, easy installation and maintenance.




Applications




                      Power Transmission

                                     UPS

                                       Telecoms



Documents

FAB12-55 2021.pdf

FAB12-100 2021.pdf

FAB12-125 2021.pdf

FAB12-150L 2021.pdf

FAB12-200 2021.pdf


Specifications:

         Model

Chemistry

Voltage (V)

Capacity (Ah)

Dimensions (mm)

Weight (Kg)

Terminal

FAB12-55

Lead-Acid

12

55

277 * 105 * 222

17.9

M6 Fem

FAB12-100

Lead-Acid

12

100

558 * 112 * 295

40.5

M8 Fem

FAB12-125

Lead-Acid

12

125

558 * 112 * 295

16.6

M8 Fem

FAB12-150L

Lead-Acid

12

150

558 * 112 * 295

48.5

M8 Fem

FAB12-200

Lead-Acid

12

200

560 * 125 * 316

56

M8 Fem
